1R-ET *14
Radial piston pump with1Flow rate and14piston
weight: 21,4 kg
| Piston type | Vg | Q (0 bar) | p(max) | Q | P |
|---|---|---|---|---|---|
| Z14 | 3.17 cm³/U | 4.59 l/min | 700 bar | 4.36 l/min | 1.64 kW |
| A14 | 5.63 cm³/U | 8.16 l/min | 550 bar | 7.75 l/min | 2.92 kW |
| B14 | 8.79 cm³/U | 12.75 l/min | 450 bar | 12.11 l/min | 4.57 kW |
| C14 | 12.66 cm³/U | 18.36 l/min | 350 bar | 17.44 l/min | 6.58 kW |
| D14 | 14.86 cm³/U | 21.54 l/min | 300 bar | 20.47 l/min | 7.72 kW |
| E14 | 17.23 cm³/U | 24.99 l/min | 250 bar | 23.74 l/min | 8.96 kW |
| F14 | 19.78 cm³/U | 28.68 l/min | 200 bar | 27.25 l/min | 10.28 kW |
