2R-ET *3
Radial piston pump with2Flow rates a3piston
weight: 13,3 kg
Piston type | Vg | Q (0 bar) | p(max) | Q | P |
---|---|---|---|---|---|
Z3 | 0.68 cm³/U | 0.98 l/min | 700 bar | 0.93 l/min | 0.35 kW |
Z3S | 0.42 cm³/U | 0.61 l/min | 700 bar | 0.58 l/min | 0.22 kW |
A3 | 1.21 cm³/U | 1.75 l/min | 550 bar | 1.66 l/min | 0.63 kW |
A3S | 0.75 cm³/U | 1.09 l/min | 550 bar | 1.04 l/min | 0.39 kW |
B3 | 1.88 cm³/U | 2.73 l/min | 450 bar | 2.6 l/min | 0.98 kW |
B3S | 1.18 cm³/U | 1.71 l/min | 450 bar | 1.62 l/min | 0.61 kW |
C3 | 2.71 cm³/U | 3.93 l/min | 350 bar | 3.74 l/min | 1.41 kW |
C3S | 1.7 cm³/U | 2.46 l/min | 350 bar | 2.34 l/min | 0.88 kW |
D3 | 3.18 cm³/U | 4.62 l/min | 300 bar | 4.39 l/min | 1.65 kW |
D3S | 1.99 cm³/U | 2.89 l/min | 300 bar | 2.74 l/min | 1.03 kW |
E3 | 3.69 cm³/U | 5.35 l/min | 250 bar | 5.09 l/min | 1.92 kW |
E3S | 2.31 cm³/U | 3.35 l/min | 250 bar | 3.18 l/min | 1.2 kW |
F3 | 4.24 cm³/U | 6.15 l/min | 200 bar | 5.84 l/min | 2.2 kW |
F3S | 2.65 cm³/U | 3.84 l/min | 200 bar | 3.65 l/min | 1.38 kW |
